Lazy person’s conclusion: be kind to yourself and buy better thread~

VGA & DVI

  • VGA: 2048*1536 - 60 frames
  • Dual channel DVI: 2560*1600 (slightly higher than 2K)

HDMI 2.0

  • Maximum bandwidth: 14.4Gbps
  • Support 4K 60Hz / 2K 144Hz
  • HDR, 10bit color depth, FreeSync technology

DP(DisplayPort) 1.4

  • Maximum bandwidth: 25.92 Gbps
  • Support 8K 30Hz / 5K 60Hz / 4K 120Hz
  • HDR, P3 color gamut, Rec2020 color space, G-SYNC technology
  • Supports “daisy chain” technology
  • Thunderbolt 3 supports DP 1.4

HDMI 2.1

  • Maximum bandwidth: 42.6 Gbps
  • Supports up to 10K (10240*5400)
  • Supports dynamic HDR and DSC display
  • Entering the stage of quantitative production

DisplayPort 2.0

  • Maximum bandwidth: 77.37 Gbps
  • Supports up to 16K (15360*8460) 60Hz
  • Support HDR 10
  • Currently it is just a conceptual parameter

Bandwidth required by mainstream displays

  • Apple XDR 6K 8bit 60Hz：29.31Gbps

  • 4K 8bit 60Hz：11.94Gbps

  • 2K 8bit 144Hz：12.74Gbps

  • 2K 8bit 60Hz：5,3Gbps

  • 1080P 8bit 240Hz：11.94Gbps

    好马配好鞍，线材只是一部分，超清显示还需要显卡和显示器的加持
